Product Overview
ASUS PRIME H510M-K R2.0 Motherboard is a micro-ATX motherboard designed for Intel LGA1200 processors. According to ASUS, the board supports 11th Gen and 10th Gen Intel Core processors, as well as compatible Pentium Gold and Celeron processors. The motherboard uses the Intel H470 chipset and supports DDR4 memory with a maximum capacity of 64GB.
The motherboard provides one PCIe x16 expansion slot, one PCIe x1 slot, one M.2 slot and four SATA 6Gb/s ports. The M.2 slot supports 2242, 2260 and 2280 devices in PCIe 3.0 x4 and SATA modes.
Key Features
- CPU Socket: Intel LGA1200
- Processor Support: 11th Gen and 10th Gen Intel Core, Pentium Gold and Celeron processors
- Chipset: Intel H470
- Memory: 2 × DDR4 DIMM slots, up to 64GB
- Expansion: 1 × PCIe 4.0/3.0 x16 and 1 × PCIe 3.0 x1
- Storage: 1 × M.2 and 4 × SATA 6Gb/s
- Networking: Realtek 1Gb Ethernet
- Display Outputs: VGA and HDMI
- Form Factor: Micro-ATX
Specifications & Compatibility
| Attribute | Verified Value |
|---|---|
| Model | PRIME H510M-K R2.0 |
| CPU Socket | Intel LGA1200 |
| CPU Support | 11th Gen & 10th Gen Intel Core, Pentium Gold and Celeron processors |
| Chipset | Intel H470 |
| Memory | 2 × DDR4 DIMM, maximum 64GB |
| Memory Architecture | Dual Channel |
| Memory Support | DDR4 3200(OC)/3000(OC)/2933/2800/2666/2400/2133 |
| Memory Type | Non-ECC, Un-buffered |
| Graphics | 1 × VGA, 1 × HDMI |
| PCIe x16 | 1 × PCIe 4.0/3.0 x16 |
| PCIe x1 | 1 × PCIe 3.0 x1 |
| M.2 | 1 × M.2 Key M, 2242/2260/2280, PCIe 3.0 x4 & SATA modes |
| SATA | 4 × SATA 6Gb/s |
| LAN | Realtek 1Gb Ethernet |
| Rear USB | 4 × USB 3.2 Gen 1 Type-A, 2 × USB 2.0 Type-A |
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC |
| Form Factor | Micro-ATX |
| Dimensions | 22.6 × 20.3 cm |
